VT2000 Panel PC，J6412，8GB+128G SSD；
Adopts Intel® Celeron® CPU J series to offer strong performance.
- Powered by an Intel® Celeron® J-series CPU for strong performance.
- Multi-channel I/O with easy-to-use setup.
- GigE interface for stable data transfer.
- Optional built-in USB interface for on-site maintenance.
- Full metal housing, rugged and durable.
- Countertop, embedded, wall-mount, and VESA-standard installation.
Camera Solutions
VT2000 Panel PC, J6412, 8GB+128G SSD； is a vision controller from HIKROBOT, supplied in the DACH region by EQ Vision under article number MV-VT2000-128G40-NN. Key data: certification CE, KC. Typical use is running image processing directly in the control cabinet. Send us the article number with your application and we will confirm availability, datasheet and integration details.
Further variants in this product family
Description
Multi-channel I/O with easy-to-use setup. GigE interface for stable data transfer. Optional built-in USB interface for on-site maintenance. Full metal housing, rugged and durable. Countertop, embedded, wall-mount, and VESA-standard installation.
Product Highlights
Powered by an Intel® Celeron® J-series CPU for strong performance. — Multi-channel I/O with easy-to-use setup. — GigE interface for stable data transfer. — Optional built-in USB interface for on-site maintenance. — Full metal housing, rugged and durable. — Countertop, embedded, wall-mount, and VESA-standard installation.
Specifications
| Product Model | MV-VT2000-128G40-NN |
|---|---|
| Type | VT2000 Panel PC，J6412，8GB+128G SSD； |
| CPU | Intel® Celeron® CPU J6412 |
| Memory | 8 GB |
| Storage | 128 GB SSD |
| Operating System | Unactivated Windows 10 2021H2 |
| Digital I/O | Supports up to opto-isolated input × 7 and opto-isolated output × 7 |
| Network Interface | GigE interface × 4 |
| USB Interface | USB 3.0 × 2 USB 2.0 × 2 |
| Serial Port | RS-232 × 2, supports switching to RS-485 and RS-422. |
| Power Supply | 24 VDC |
| Power Consumption | Typ. 30 W |
| Dimension | 255 mm × 170 mm × 63 mm (10.0" × 6.7" × 2.5") |
| Weight | Approx. 2 kg (10.6 lb.) |
| Temperature | Working temperature: 0 °C to 50 °C (32 °F to 122 °F) (wind speed 0.7 m/s) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
| Humidity | 20% RH to 80% RH (no condensation) |
| Certification | CE, KC |
| Display Interface | HDMI interface × 1 (1920 × 1080 @ 60 Hz) |
| Screen Size | 10.1 inches |
| Resolution | 1280 × 800 |
| Backlight | LED |
| Backlight Lifetime | ≥ 30000 hrs |
| Viewing Angle | 85°(R)/ 85°(L)/ 85°(B)/ 85°(T) |
| Contrast Ratio | 800:1 |
| Brightness | 350 cd/m2 (TYP) |
| Touch Type | Multi-point capacitive touch screen |
| Multi Touch | Touch supports with 10 points under Windows operating system |
| Touch Times | ≥ 35 million times |
| Transmittance | ≥ 85% |
| Surface Hardness | 6 H |
