Dual WX1860 Ehternet Adaptor W/O POE
Supports IEEE 802.3 protocol.
Nicht gefunden was Sie suchen?
Markus Berger
Sales & Business Development Manager
Camera Solutions
markus.berger@eqphotonics.de
Anfrage stellen
Camera Solutions
Beschreibung
Multiple independent RJ45 connectors. Fits 3U and 4U chassis.
Product Highlights
Complies with the IEEE 802.3 standard. — Multiple independent RJ45 connectors. — Fits 3U and 4U chassis.
Specifications
| Product Model | MV-GE2202 |
|---|---|
| Type | Dual WX1860 Ehternet Adaptor W/O POE |
| Certification | CE, KC |
| Interface | RJ45 × 2 |
| Interconnect | PCI-E gen2 × 4 |
| Delivery Bandwidth | 860 MB/s (max. transmission bandwidth) 800 MB/s (sustained transmission bandwidth) |
| Standard | IEEE 802.3 |
| Camera Type Supported | GigE industrial camera |
| Camera Quantity Supported | 2 at most |
| Camera Connection Speed | 10/100/1000 Mbps |
| Stream | 2 |
| Power Consumption | Typ. 2 W |
| Dimension | 181 mm × 126.3 mm × 21.6 mm (7.1" × 5.0" × 0.9") |
| Temperature | Working temperature: 0 °C to 60 °C (32 °F to 140 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F) |
| Humidity | 10% RH to 95% RH (no condensation) |
| Operating System | Windows 7, 64-bit Windows 10, Linux |
| Weight | 190 g (0.4 lb.) |
| Main Chip | WX1860 chip |
