Dual ports WX1860 POE Ethernet Adaptors

Name: Dual ports WX1860 POE Ethernet Adaptors
Brand: HIKROBOT
SKU: MV-GE2202P

Supports IEEE 802.3 protocol.

Send inquiry

Download datasheet (PDF)

Highlights

Complies with the IEEE 802.3 standard.
Multiple independent RJ45 connectors.
Fits 3U and 4U chassis.
PoE supported with up to 15.4 W per channel.

Not found what you are looking for?

Markus Berger

Sales & Business Development Manager
Camera Solutions

markus.berger@eqphotonics.de Send inquiry

SKU: MV-GE2202P Category: Vision Components

Dual ports WX1860 POE Ethernet Adaptors is a vision component from HIKROBOT, supplied in the DACH region by EQ Vision under article number MV-GE2202P. Key data: certification CE, KC. Typical use is connecting and powering machine vision systems. Send us the article number with your application and we will confirm availability, datasheet and integration details.

Further variants in this product family

Description

Description

Multiple independent RJ45 connectors. Fits 3U and 4U chassis. PoE supported with up to 15.4 W per channel.

Product Highlights

Complies with the IEEE 802.3 standard. — Multiple independent RJ45 connectors. — Fits 3U and 4U chassis. — PoE supported with up to 15.4 W per channel.

Specifications

Product Model	MV-GE2202P
Type	Dual ports WX1860 POE Ethernet Adaptors
Certification	CE, KC
Interface	RJ45 × 2
Interconnect	PCI-E gen2 × 4
Delivery Bandwidth	860 MB/s (max. transmission bandwidth) 800 MB/s (sustained transmission bandwidth)
Standard	IEEE 802.3
Camera Type Supported	GigE industrial camera
Camera Quantity Supported	2 at most
Camera Connection Speed	10/100/1000 Mbps
Stream	2
Power Consumption	Typ. 2 W (without PoE)
Dimension	181 mm × 126.3 mm × 21.6 mm (7.1" × 5.0" × 0.9")
Temperature	Working temperature: 0 °C to 60 °C (32 °F to 140 °F) Storage temperature: –30 °C to 70 °C (–22 °F to 158 °F)
Humidity	10% RH to 95% RH (no condensation)
Operating System	64-bit Windows 7/10/11, Linux
Weight	190 g (0.4 lb.)
Main Chip	WX1860 chip
