Area Scan Camera, 5MP, USB3.0, Color

Name: Area Scan Camera, 5MP, USB3.0, Color
Brand: HIKROBOT
SKU: MV-CS050-80UC

Adopts brand new structure design and supports installation from four sides.

Send inquiry

Download datasheet (PDF)

Highlights

Fresh structural design supports installation from four sides.
Super Palette and Super Bayer deliver high-quality images.
Offers auto or manual gain, exposure, white balance, LUT, and gamma correction, plus Sequencer.
Supports hardware trigger, software trigger, and anyway mode.
Works with the USB3 Vision protocol, the GenICam standard, and compatible third-party software.

Not found what you are looking for?

Markus Berger

Sales & Business Development Manager
Camera Solutions

markus.berger@eqphotonics.de Send inquiry

SKU: MV-CS050-80UC Category: Area & Line Scan Cameras

Area Scan Camera, 5MP, USB3.0, Color is a industrial camera from HIKROBOT, supplied in the DACH region by EQ Vision under article number MV-CS050-80UC. Key data: resolution 2448 × 2048, sensor type CMOS, global shutter, max frame rate 80 fps @ 2448 × 2048 Bayer BG 8, data interface USB 3.0, compatible with USB 2.0. Typical use is automated inspection, measurement and robot guidance. Send us the article number with your application and we will confirm availability, datasheet and integration details.

Further variants in this product family

Description

Description

Super Palette and Super Bayer deliver high-quality images. Offers auto or manual gain, exposure, white balance, LUT, and gamma correction, plus Sequencer. Supports hardware trigger, software trigger, and anyway mode. Works with the USB3 Vision protocol, the GenICam standard, and compatible third-party software.

Area Scan Camera, 5MP, USB3.0, Color (MV-CS050-80UC) at a glance: 2448 × 2048 resolution, SS sensor, 2/3" sensor format, 3.45 μm × 3.45 μm pixel size, up to 80 fps, USB 3.0, compatible with USB 2.0 interface, C-mount lens mount and 29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2") housing. The complete specification table is on this page; use the inquiry button for pricing, availability and application advice from EQ Vision.

Product Highlights

Fresh structural design supports installation from four sides. — Super Palette and Super Bayer deliver high-quality images. — Offers auto or manual gain, exposure, white balance, LUT, and gamma correction, plus Sequencer. — Supports hardware trigger, software trigger, and anyway mode. — Works with the USB3 Vision protocol, the GenICam standard, and compatible third-party software.

Specifications

Product Model	MV-CS050-80UC
Type	Area Scan Camera, 5MP, USB3.0, Color
Sensor Type	CMOS, global shutter
Sensor Model	SS
Pixel Size	3.45 μm × 3.45 μm
Sensor Size	2/3"
Resolution	2448 × 2048
Max Frame Rate	80 fps @ 2448 × 2048 Bayer BG 8
Dynamic Range	61.8 dB
SNR	41.8 dB
Gain	0 dB to 12 dB
Exposure Time	15 μs to 10 sec
Exposure Mode	Off/Once/Continuous exposure mode
Pixel Format	Mono 8 Bayer BG 8/10/10Packed/12/12Packed YUV422Packed, YUV422_YUYV_Packed RGB 8, BGR 8
Binning	Supports 1 × 1, 2 × 2, 4 × 4
Decimation	Supports 1 × 1, 2 × 2, 4 × 4
Reverse Image	Supports horizontal and vertical reverse image output
Data Interface	USB 3.0, compatible with USB 2.0
Digital I/O	6-pin P7 connector provides power and I/O, including opto-isolated input × 1 (Line 0), opto-isolated output × 1 (Line 1), bi-directional non-isolated I/O × 1 (Line 2).
Power Supply	9 VDC to 24 VDC, supports USB 3.0 power supply
Lens Mount	C-mount
Dimension	29 mm × 29 mm × 30 mm (1.1" × 1.1" × 1.2")
Weight	Approx. 87 g (0.2 lb.)
Ingress Protection	IP40 (under proper lens installation and wiring)
Temperature	Working temperature: –30 °C to 60 °C (–22 °F to 140 °F) Storage temperature: –30 °C to 80 °C (–22 °F to 176 °F)
Humidity	20% RH to 95% RH (no condensation)
Client Software	MVS or third-party software meeting with USB3 Vision Protocol
Operating System	32/64-bit Windows 7/10, 64-bit Windows 11, and 32/64-bit Linux
Compatibility	USB3 Vision, GenlCam
Certification	CE, RoHS, KC
Mono	Color
Power Consumption 2	Typ. 1.6 W @ 5 VDC (USB 3.0 provides power supply)
Quantum Efficiency	68.97 %
Dark Noise	11.7e- @ 12 bit
Saturation Capacity	15.2 ke-
