M42-Mount Lens, 40mm, F2.8, Image Size φ37mm, Recommended Magnification 0.04~0.22X
Provides excellent consistency of image clarity.
- Excellent image-clarity consistency.
- Large aperture, low distortion, low chromatic aberration, and high relative illumination.
- Maximum image size Ø37 mm; suits APS-C area-scan and 4K line-scan cameras.
Camera Solutions
M42-Mount Lens, 40mm, F2.8, Image Size φ37mm, Recommended Magnification 0.04~0.22X is a machine vision lens from HIKROBOT, supplied in the DACH region by EQ Vision under article number MVL-AF4028M-M42. Key data: focal length 40 mm, f number F2.8 to F22, mount M42 × P1, image size Φ37 mm. Typical use is imaging onto industrial camera sensors. Send us the article number with your application and we will confirm availability, datasheet and integration details.
Further variants in this product family
- Adapter Ring M42×1.0-F T34.5 (M42x1.0-F T34.5)
- Adapter Ring M58×0.75-C T6.02 (M58x0.75-C T6.02)
- Adapter Ring M58×0.75-F T35 (M58x0.75-F T35)
- C-Mount Lens, 12mm, F2.0, 4/3″, 10MP (SA1220M-10MP)
- C-Mount Lens, 12mm, F2.4, 1.2″, 25MP (MVL-KF1224M-25MP)
- C-Mount Lens, 12mm, F2.4, 1/1.8″, 10MP (MVL-HF1224M-10MP)
- C-Mount Lens, 12mm, F2.4, 2/3″, 5MP (MVL-MF1224M-5MPE)
- C-Mount Lens, 12mm, F2.8, 1.1″, 12MP (MVL-KF1228M-12MPE)
Description
Large aperture, low distortion, low chromatic aberration, and high relative illumination. Maximum image size Ø37 mm; suits APS-C area-scan and 4K line-scan cameras.
Product Highlights
Excellent image-clarity consistency. — Large aperture, low distortion, low chromatic aberration, and high relative illumination. — Maximum image size Ø37 mm; suits APS-C area-scan and 4K line-scan cameras.
Specifications
| Product Model | MVL-AF4028M-M42 |
|---|---|
| Type | M42-Mount Lens, 40mm, F2.8, Image Size φ37mm, Recommended Magnification 0.04~0.22X |
| Focal Length | 40 mm |
| F Number | F2.8 to F22 |
| Image Size | Φ37 mm |
| Iris Control | Manual |
| Focus Control | Manual |
| Filter Thread | M37 × 0.75 |
| Mount | M42 × P1 |
| Flange Back Length | 12 mm |
| Dimension | Φ47.6 mm × 62.7 mm (Φ1.9" × 2.5") |
| Weight | 171 g (0.4 Ib.) |
| Temperature | –10 °C to 50 °C (14 °F to 122 °F) |
| Certification | RoHS 2.0 |
| Optical Distortion | 0.62% |
| Magnification Range | 0.22 x to 0.04 x |
| Working Distance Range | 200 mm to 1051 mm |
