Camera Link cable(SDR-SDR)，standard，3m
The Camera Link Standard Data Cable can be used for data transmission of Camera Link interface cameras, and is available in a variety of lengths.
Nicht gefunden was Sie suchen?
Markus Berger
Sales & Business Development Manager
Camera Solutions
markus.berger@eqphotonics.de
Anfrage stellen
Camera Solutions
Product Highlights
Camera Link Standard Data Cables carry Camera Link data; available in multiple lengths.
Specifications
| Product Model | MV-ACCL-SDR-SDR-ST-3m |
|---|---|
| Type | Camera Link cable(SDR-SDR)，standard，3m |
| End A Connector | SDR |
| End B Connector | SDR |
| Cable Diameter | 9.5 mm |
| Length | 3 m |
| Cable Mechanical | (28AWG*1P+AL)*11C+28AWG*2C+MY+AL+B, UL20276 |
| Jacket | PVC |
| Cable Color | Black |
| Connector Durability | ≥500 cycles |
| Min Bending Radius | 114 mm |
| Applicable Scenario | Static scenes |
| Max Voltage | 30 VDC |
| Working Temperature | -20°C~80°C |
| Certification | RoHS,UL |
| Packaging | Individual package |
