Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 3 m
The RJ45 Standard 10 Gigabit Ethernet Cable can be used for data transmission of RJ45 10 Gigabit Ethernet interface cameras, and is available in a variety of lengths.
Not found what you are looking for?
Markus Berger
Sales & Business Development Manager
Camera Solutions
markus.berger@eqphotonics.de
Send inquiry
Camera Solutions
Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 3 m is a vision component from HIKROBOT, supplied in the DACH region by EQ Vision under article number MV-AC10G-RJ45s-RJ45-ST-3m. Key data: certification RoHS,UL. Typical use is connecting and powering machine vision systems. Send us the article number with your application and we will confirm availability, datasheet and integration details.
Further variants in this product family
- Fiber Optic Cable, LC (2-core) to LC (2-core), 3 m (MV-AC10G-2LC-2LC-ST-3m)
- Fiber Optic Cable, LC (2-core) to LC (2-core), 5 m (MV-AC10G-2LC-2LC-ST-5m)
- Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 10 m, High-Flex (MV-AC10G-RJ45s-RJ45-HF-10m)
- Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 3 m, High-Flex (MV-AC10G-RJ45s-RJ45-HF-3m)
- Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 5 m, High-Flex (MV-AC10G-RJ45s-RJ45-HF-5m)
- Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 10 m (MV-AC10G-RJ45s-RJ45-ST-10m)
- Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 5 m (MV-AC10G-RJ45s-RJ45-ST-5m)
- MV-AC10G-SFP-850-LC
Product Highlights
RJ45 Standard 10 GigE Cables carry data for 10 GigE cameras; available in multiple lengths.
Specifications
| Product Model | MV-AC10G-RJ45s-RJ45-ST-3m |
|---|---|
| Type | Fiber Optic Cable, RJ45 (with locking stud) to RJ45, 3 m |
| End A Connector | RJ45 (with locking stud) |
| End B Connector | RJ45 |
| Cable Diameter | 7.0 mm |
| Length | 3 m |
| Cable Mechanical | (26#*1P+AL)*4C+AB |
| Jacket | PVC |
| Cable Color | Black |
| Connector Durability | >750 cycles |
| Min Bending Radius | 84 mm |
| Applicable Scenario | Static scenes |
| Max Voltage | 30 VDC |
| Working Temperature | -20°C~ 75°C |
| Certification | RoHS,UL |
| Packaging | Individual package |
